Dimensions:
Weight: 14.9 oz
Footprint: 5.25” x 7.63”
Combined deck thickness: .33”
Design Features: *Denotes new feature
*100% engineered and manufactured in America.
*Configurable (or removable) rubber cleats for enhanced bag retention.
*Aluminum baseplate and ARCA rail hardcoat anodized to MIL-A-8625 Type III.
*KADI designed 2.6” long ARCA rail, for mounting to industry standard ball heads, is pocketed into the baseplate eliminating rotation. Fasteners installed with medium thread locker and torqued for secure fitment
*Optional 3/8-16 countersunk clearance hole can be added to your Ute 2 ARCA rail for direct mounting to tripod.
*Clipped corners reduce weight.
-Lightening windows double as grips, lashing points, and visual access to confirm position of locking levers, etc.
-Kydex top deck with a single lip for bag support or to hold small items (phone, DOPE book, Kestrel, etc.) when tilted to sheet music stand orientation. It doesn’t abrade gear or scuff optics/ chassis: attached with countersunk screws for a clean profile. Profiles left at 90 degrees for edge grip.
Attachment Capabilities: *Denotes new feature
*Magpul approved M-LOK slots located at the center and edge for mounting ARCA clamps, picatinny rails/ attachments, or devices threaded for 1/4-20 fasteners.
-Multiple 1/4-20 tapped holes around the lightening windows for mounting ball heads, binos, GoPros, etc., or use for lashing.
-Perimeter arcs cut to cradle your shooting bag when placed mouth down.
Notes & Care:
-ARCA rail screw torque: 35 in/lbs (reapply thread locker if retorquing).
-Avoid over-tightening Kydex mounting screws to prevent damage.
-Follow Magpul prescribed M-LOK tightening specs.
